Atlas HO Silver RS3 Burlington Northern 4068

FEATURES:

• DCC/Sound version available with LokSound decoder

• Analog version includes an 8-pin socket for DCC

• Improved tooling on turbo exhaust stack. Also includes option of water cooled or

aicooled turbo exahust stack

• Separately-applied handrails and stanchions, including separate drop step detail

• Factory installed AccuMate® couplers

• Dual flywheel-equipped five-pole skewed armature motor for optimum

performance at all speeds

• Metal grab irons

• Accurate painting and printing

DCC Operation

• Supports all DCC-programming modes

• Flexible mapping of function keys F0 to F28.

• A total of six DCC function outputs are available

• Follows all NMRA DCC standards and recommended practices.

Analog (DC) Operation

• The LokSound Select Dual-Mode decoder allows your Atlas Gold Series locomotive

to be used on DC as well as on DCC layouts.

• Please note that the Atlas Quantum Engineer will NOT operate an Atlas Gold Series

locomotive equipped with a LokSound Select decoder on an analog (DC) layout

However, the sound and lighting functions of the LokSound Select decoder in the Atlas

• Gold Series locomotive can be controlled by an easy-to-use basic DCC system. Also note

that on a DC-powered layout, a DCC and sound equipped locomotive CANNOT be

consisted with another locomotive that does not also have both DCC and sound. (This

statement does NOT apply to DCC-equipped locomotives operating on a DCC layout.)

Sound Functionality

• Over 20 sound effects are available, including engine start-up and shutdown, prime

mover sounds through all eight notches, bell, air horn, air compressor, dynamic brakes

and more.

• There are 16 user-selectable horns, 2 user-selectable bells, and 2 user-selectable

synchronized brake queals.

• Manual and Automatic Notching modes with the ability to change modes “on the fly”

are provided for true realism.
